CR2025 3.0V 160mA Primary Lithium Coin Cell Battery for LED Light

Product Categories

Guang Zhou Sunland New Energy Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Add to Cart

Battery Type	button coin cell 3v lithium battery CR2025
Brand Name	TAC or OEM
Model	CR2025 CR2016 CR2032 CR2450 CR1620 CR1616
Voltage	3.0V
Material	Lithium Manganese Battery
Capacity	75mAh- 600mAh
Certifications	CE ROHS SGS MSDS
Size	20.0mm*15mm
Jacket	Bare or Yellow Pvc
Samples Service	Free samples available
If Rechargeable	No
Storage life	1year
Package	Blister card pack,bulk tray pack or your customized package
Shipping	2-3 working days for samples; 15-20 days for batch goods.
Payment Term	T/T, L/C, Paypal, etc

Similar products:

OBA check below item list after we shipping out

No	ITEM	TEST METHODS	STANDARED
1	Dimensions	Using vernier caliper (accuracy≥0.02) while avoiding short-circuit	Diameter	20.0 (-0.2) mm
1	Dimensions		Height	2.5 (-0.2) mm
2	Off-load voltage	Using multimeter (accuracy≥0.25%) internal resistance≥1MΩ	≥3.25 v
3	Instantaneous short-circuit current	Time of short-circuit should be less than 0.5 second and avoid repeated test within half an hour	≥160 mA
4	Appearance	Eyeballing	Bright, clean, no rust, no leakage, And no flaw
5	Capacity	Continuously discharge for 8 hours with load 15k, temperature at 20~25℃, humidity at 65±20% till 2.0v end-voltage (for fresh battery only: within 3 months )	≥1000 h
6	Vibration test	Put battery on the platform of the vibrations machine, start the machine and adjust the frequency form 10 times per minute to 15 times per minute. keep it running for an hour	Characteristics keep stability
7	Leakage at high temperature	Stored under temperature (45℃) for 30 days	Leakage rate≤1%
8	Over discharge Test	After 2.0v end-voltage, continuously discharged for 5 hours	No leakage allowed
