Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy

    Buy cheap Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy from wholesalers

    Buy cheap Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy from wholesalers
    • Buy cheap Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy from wholesalers
    • Buy cheap Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy from wholesalers
    • Buy cheap Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy from wholesalers
    • Buy cheap Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy from wholesalers

    Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy

    Ask Lasest Price
    Brand Name : TAC
    Model Number : LP052030
    Certification : UL, Rohs
    Price : usd 3.0
    Delivery Time : 14days after order
    Payment Terms : T/T, LC, Paypal etc.
    Supply Ability : 30K/Day
    • Product Details
    • Company Profile

    Polymer Lithium Ion Batteries LP052030 3.7V 260mAh for Toy


    High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Toy


    Feature:


    1. The batteries used in aeromodelling toy
    2. Place of Origin Guangdong China (Mainland)
    3. Brand Name TAC
    4. Model Name; LP052030
    5. Battery Type :polymer lithium-ion battery
    6. Nominal Voltage 3.7V
    7. Nominal Capacity 260mAh
    8. Size :5mm(T)*20mm(w)30mm(h)


    Specification For     High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Toy

    No.

    Item

    Rated Performance

    Remark

    1

    Rated Capacity

    Minimum

    260mAh

    Standard discharge(0.2C C5A)
    after Standard charge

    2

    Nominal Voltage

    3.7V

    Mean Operation Voltage During Standard Discharge After
    Standard Charge

    3

    Voltage at end of
    Discharge

    3.0V

    Discharge Cut-off Voltage

    4

    Charging Voltage

    4.2±0.03V


    5

    AC (1KHz) Impedance
    New Cell Max.(mW)

    ≤80mΩ


    6

    Standard charge

    Constant Current 0.5C5A
    Constant Voltage 4.2V
    0.01 C5A cut-off

    Charge time : Approx 4.0h

    7

    Standard discharge

    Constant current 0.2 C5A
    end voltage 3.0 V


    8

    Fast charge

    Constant Current 1C5A
    Constant Voltage 4.2V
    0.01 C5A cut-off

    Charge time : Approx 2.5h

    9

    Fast discharge

    Constant current 1 C5A
    end voltage 3.0 V


    10

    Maximum Continuous
    Charge Current

    1 C5A


    11

    Maximum Continuous
    Discharge Current

    1.5 C5A


    12

    Operation Temperature Range

    Charge: 0~45℃

    60±25%R.H.
    Be Cell

    Discharge: -20~60℃

    13

    Storage Temperature
    Range

    Less than 1 year: -20~25℃

    60±25%R.H.
    at the shipment state

    less than 3 months: -20~40℃

    14

    Weight

    Approx :40g

    Bare Cell

    15

    Cell Dimension

    Length: Max.3m0m

    Initial Dimension

    Width: Max.20mm

    Thickness: Max. 5mm


    Pictures:
    High Capacity GSP052030 3.7V 260mAh Polymer Lithium Ion Batteries for toy

    The dimension measurement shall be implemented by instruments with equal or more precision scale of 0.01mm.

    High Capacity GSP052030 3.7V 260mAh Polymer Lithium Ion Batteries for aeromodelling toy


    Application


    Global localization satellite GPS, Bluetooth, portable type media products(Mp3, Mp4, DVD), notebook, tablet PC, the electronic toy, e-bike, model ship,

    the power tool, camera, the multi-purpose PDA telephones.

    Similar Production List

    Model

    Nominal Voltage (V)

    Typical Cap.

    Dimension(mm)

    (mm)

    Thickness

    Width

    Height

    073496DHP

    3.7

    2100

    7.8

    34

    96

    LP0567100

    3.7

    3400

    4.8

    67

    100

    LP066166

    3.7

    2750

    6.1

    61

    66

    LP555376

    3.7

    2300

    5.6

    53

    76

    LP085065

    3.7

    2600

    7.8

    50

    65

    LP085080

    3.7

    3400

    8

    50

    80

    LP0845131

    3.7

    5100

    7.5

    45

    131

    LP0831134

    3.7

    4000

    8.1

    31

    132

    LP55100100

    3.7

    5600

    5.5

    100

    100

    LP605590

    3.7

    3400

    6

    55

    90

    LP9051109

    3.7

    5500

    9

    51

    109

    LP9551119

    3.7

    6800

    9.5

    51

    119

    *LP7044125

    3.7

    4200

    7

    44

    125

    *LP7545135

    3.7

    4500

    7.5

    45

    135

    LP704374

    3.7

    2200

    7

    43

    74

    LP854374

    3.7

    3000

    8.5

    43

    74


    Package Photo


    Aging Equipment


    Charge and discharge the battery cell to sort the full 100% truth capacity
