High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Communicator

Ask Lasest Price
Brand Name :	TAC
Certification :	UL, Rohs
Model Number :	LP052030
Price :	usd 0.5 each pcs
Delivery Time :	14days after order
Payment Terms :	T/T, LC, Paypal etc.
Supply Ability :	30K/Day

Add to Cart

Product Details
Company Profile

High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Communicator

High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Communicator

Production Description for High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Communicator

No.	Item	Rated Performance		Remark
1	Rated Capacity	Minimum	200-260mAh	Standard discharge(0.2C C5A) after Standard charge
2	Nominal Voltage	3.7V		Mean Operation Voltage During Standard Discharge After Standard Charge
3	Voltage at end of Discharge	3.0V		Discharge Cut-off Voltage
4	Charging Voltage	4.2±0.03V
5	AC (1KHz) Impedance New Cell Max.(mW)	≤80mΩ
6	Standard charge	Constant Current 0.5C5A Constant Voltage 4.2V 0.01 C5A cut-off		Charge time : Approx 4.0h
7	Standard discharge	Constant current 0.2 C5A end voltage 3.0 V
8	Fast charge	Constant Current 1C5A Constant Voltage 4.2V 0.01 C5A cut-off		Charge time : Approx 2.5h
9	Fast discharge	Constant current 1 C5A end voltage 3.0 V
10	Maximum Continuous Charge Current	1 C5A
11	Maximum Continuous Discharge Current	1.5 C5A
12	Operation Temperature Range	Charge: 0~45℃		60±25%R.H. Be Cell
		Discharge: -20~60℃
13	Storage Temperature Range	Less than 1 year: -20~25℃		60±25%R.H. at the shipment state
		less than 3 months: -20~40℃
14	Weight	Approx :15g		Bare Cell
15	Cell Dimension	Length: Max.30mm		Initial Dimension
		Width: Max.20mm
		Thickness: Max. 5.5mm

Pictures:

High Capacity LP052030 3.7V 260mAh Polymer Lithium Ion Batteries for Communicator

There are two model options for 200-270mah cell to meet your size require .

MODEL	CAPACITY	MIN CAPACITY	INNER RESISTANCE	VOLTAGE	PERFORMANCE		MAX SIZE/mm
MODEL	mAh	mAh	mΩ	V	charge current	discharge current	T	W	H
042030	200	200	150	3.7	≤1C	≤1C	4.1	20.5	30.5
452530	270	270	100	3.7	≤1C	≤1C	4.5	25.5	30.0

Application

Global localization satellite GPS, Bluetooth, portable type media products(Mp3, Mp4, DVD), notebook, tablet PC, the electronic toy, e-bike, model ship, the power tool, camera, the multi-purpose PDA telephones.

Feature for polymer rechargeable battery

Design and develop products according to customer's requirements and expectations

Safer

Higher energy density

Higher capacity

Small inner resistance

Thinner

Lighter

1. Light weight, high capacity, low inner resistance, good discharge performance.

2. High energy density, no memory effect, no pollution, has good plastic style.

3. Use polymer material, cell no explode, no burn, applied range is wide.

There are a variety of model, various capacity to choose from.

Model	Nominal Voltage (V)	Typical Cap.	Dimension(mm)
Model	Nominal Voltage (V)	(mm)	Thickness	Width	Height
073496DHP	3.7	2100	7.8	34	96
LP0567100	3.7	3400	4.8	67	100
LP066166	3.7	2750	6.1	61	66
LP555376	3.7	2300	5.6	53	76
LP085065	3.7	2600	7.8	50	65
LP085080	3.7	3400	8	50	80
LP0845131	3.7	5100	7.5	45	131
LP0831134	3.7	4000	8.1	31	132
LP55100100	3.7	5600	5.5	100	100
LP605590	3.7	3400	6	55	90
LP9051109	3.7	5500	9	51	109
LP9551119	3.7	6800	9.5	51	119
LP7044125	3.7	4200	7	44	125
LP7545135	3.7	4500	7.5	45	135
LP704374	3.7	2200	7	43	74
LP854374	3.7	3000	8.5	43	74

Pakage Standard
