3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV

    Buy cheap 3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV from wholesalers

    Buy cheap 3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV from wholesalers
    • Buy cheap 3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV from wholesalers
    • Buy cheap 3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV from wholesalers

    3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV

    Ask Lasest Price
    Brand Name : TAC OEM & ODM
    Model Number : 48V 60Ah 2.9KWh
    Certification : MSDS REACH ROHS
    Price : usd500-2000 / kwh
    Payment Terms : 100% prepaid before shipping out
    Supply Ability : 100000PCS EACH WEEK
    Delivery Time : 7-10 days after order confirm for stock model
    • Product Details
    • Company Profile

    3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV

    3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV


    Quick Detail For 3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV


    Place of Origin:Guang dong ChinaBrand Name:TAC
    Nominal Voltage:48VRated Capacity:60Ah
    Type:Li-IonSize:600*190*443mm
    Noise emission<40dBDisplayLCD
    ColorWhite/Black(customized)Protection DegreeIP20
    Weight:40kgCertificationUN, ROHS, REACH ,BIS
    OEM & ODM:SupportWarranty:12months

    Features for 3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV

    1. Li-Ion Lithium Battery 48V60Ah 2.9KWh.

    2. Lighter weight, smaller size.

    3. Display: LCD

    4. Environmentally friendly non-toxic, non-contaminating, no rare metal.


    3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV Specification:


    ParametersES2.9KWhPV1
    Battery TypeLi-Ion
    Rated Voltage/ Capacity48V/60Ah
    Rated Energy2.9KWh
    Usable Capacity (80%DOD)2.3KWh
    Voltage Range45~54.7VDC
    Rated Discharge Current25A
    Max. Discharge Current60A
    Standard Charge Current25A
    Max.Charge Current60A
    Operating TemperatureCharge:0°C ~50°C;
    Discharge -20°C~50°C;
    Storage Temperature-20°C~50°C
    Ambient HumidityMax. 90[%Rh] *Non Condensing
    Expected Lifetime (25°C/+77℉)>5 Years
    Cycle life (80% DOD, 25°C/+77℉)>2000Cycles
    Max. operating altitude2000m
    Dimensions(W*H*D)600*190*443mm
    Weight40kg
    ColorWhite/Black(customized)
    Protection DegreeIP20
    CoolingNatural
    Noise emission<40dB
    DisplayLED light
    InterfaceRS232,RS485

    3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV indication


    StatusChargeDischarge
    Capacity

    L4

    L3

    L2

    L1

    L4

    L3

    L2

    L1

    0~25%OffOffOffFlashOffOffOffOn
    25~50%OffOffFlashOnOffOffOnOn
    50~75%OffFlashOnOnOffOnOnOn
    ≥75%OnOnOnOnOnOnOnOn
    Status ●OnFlash

    Application for 3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV


    Delivery Time

    25days for normal standard module

    35 days for OEM order

    Package Pictures

    The battery pack protect with wood container one by one



    Production Picture


    Period of Warranty

    The period of warranty is one year from the date of shipment. TAC guarantees to give a replacement in case of cells with defects proven due to manufacturing process instead of the customers abuse and misuse.

    Storing the Batteries

    The battery should store in the product specification book stipulation temperature range. If has surpasses above for three to six months the long time storage, suggested you should carry on additional charge to the battery.
