3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV

Ask Lasest Price
Brand Name :	TAC OEM & ODM
Model Number :	48V 60Ah 2.9KWh
Certification :	MSDS REACH ROHS
Price :	usd500-2000 / kwh
Payment Terms :	100% prepaid before shipping out
Supply Ability :	100000PCS EACH WEEK
Delivery Time :	7-10 days after order confirm for stock model

Add to Cart

Product Details
Company Profile

3KWh Lithium Ion Cylindrical Battey Pack Energy Storage System For EV

3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV

Quick Detail For 3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV

Place of Origin:	Guang dong China	Brand Name:	TAC
Nominal Voltage:	48V	Rated Capacity:	60Ah
Type:	Li-Ion	Size:	600190443mm
Noise emission	<40dB	Display	LCD
Color	White/Black(customized)	Protection Degree	IP20
Weight:	40kg	Certification	UN, ROHS, REACH ,BIS
OEM & ODM:	Support	Warranty:	12months

Features for 3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV

1. Li-Ion Lithium Battery 48V60Ah 2.9KWh.

2. Lighter weight, smaller size.

3. Display: LCD

4. Environmentally friendly non-toxic, non-contaminating, no rare metal.

3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV Specification:

Parameters	ES2.9KWhPV1
Battery Type	Li-Ion
Rated Voltage/ Capacity	48V/60Ah
Rated Energy	2.9KWh
Usable Capacity (80%DOD)	2.3KWh
Voltage Range	45～54.7VDC
Rated Discharge Current	25A
Max. Discharge Current	60A
Standard Charge Current	25A
Max.Charge Current	60A
Operating Temperature	Charge:0°C ~50°C；
Operating Temperature	Discharge -20°C~50°C;
Storage Temperature	-20°C~50°C
Ambient Humidity	Max. 90[%Rh] *Non Condensing
Expected Lifetime (25°C/+77℉)	＞5 Years
Cycle life (80% DOD, 25°C/+77℉)	＞2000Cycles
Max. operating altitude	2000m
Dimensions(WHD)	600190443mm
Weight	40kg
Color	White/Black(customized)
Protection Degree	IP20
Cooling	Natural
Noise emission	<40dB
Display	LED light
Interface	RS232,RS485

3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV indication

Status	Charge				Discharge
Capacity	L4	L3	L2	L1	L4	L3	L2	L1
0～25%	Off	Off	Off	Flash	Off	Off	Off	On
25～50%	Off	Off	Flash	On	Off	Off	On	On
50～75%	Off	Flash	On	On	Off	On	On	On
≥75%	On	On	On	On	On	On	On	On
Status ●	On				Flash

Application for 3KWh Lithium Ion Cylindrical Battery Pack Energy Storage System For EV

Delivery Time

25days for normal standard module

35 days for OEM order

Package Pictures

The battery pack protect with wood container one by one

Production Picture

Period of Warranty

The period of warranty is one year from the date of shipment. TAC guarantees to give a replacement in case of cells with defects proven due to manufacturing process instead of the customers abuse and misuse.

Storing the Batteries

The battery should store in the product specification book stipulation temperature range. If has surpasses above for three to six months the long time storage, suggested you should carry on additional charge to the battery.
