Lipo Battery For Unmanned Aerial Vehicle battery pack 11.1v 35C
5000mah
High Voltage UAV Drone Agricultural Plant Protection Lithium
polymer Battery 11.1V 5000mAh with 3S
battery capacity up 15%25% than ordinary Lithium battery.
Quick Data for Lipo Battery For Unmanned Aerial Vehicle battery
pack 11.1v 35C 5000mah
- Nominal Capacity : 5000 mAh
- Minimum. Capacity : 4900 mAh
- Nominal Voltage 11.1 V
- Charge Voltage: 12.6 ± 0.06V
- Charge Current Standard charge: 0.5 C ( 2500 mA)
- Charging Time Standard charge: 3.0 hours (Ref.) Rapid charge : 2.0
hours
- Max. charge current 1.0 C ( 5A)
- Cont.. Discharge Current 25.0 C ( 125A)
- Max. Discharge Current 50.0( 250A)
- Cutoff Voltage 9V
- Resistance ≤ 10mΩ 1kHz AC Metho
- Weight (Approx.) 400g
- circle life: 500 times , 80% for original capacity after the
battery have been stocked 1 year
Packing method for Unmanned Aerial Vehicle battery pack
1 set / foam bag , 1 bag / box , 20 box / carton with International
shipping standard
strong export paper carton
Storage Characteristics
Capacity after storage for 28 days at 25℃ from the standard charge,
measured with discharge current
Capacity retention (after the storage) over 5000mah (85% of the
capacity at 25℃)
Warranty:
Tac battery will be responsible for replacing the cell against
defects or poor workmanship
for 12 months from the date of shipping. Any other problem caused
by malfunction of the equipment or mix-use of the cell is not under
this warranty.
FAQ
Q: Can you accept OEM and ODM service?
A: Yes, We supply OEM&ODM service as clients requirement cover
lithium-ion lifepo4 polymer lithium cell and pack
Q: Can we get samples
A: Sure , we support free samples less than 2 pcs for singlce cell
base on the buyer charged the express fee.
Q: What's your payment term?
A: TT/ LC/ PAYPAL etc
Q: What's your warranty for production?
A: 1 year for all the production
Q: How Long will be the delivery ?
A: 7-10 days for the single standard model after the order confirm
25-35 days for the OEM ODM order
Q: How do you control your production quality
A: We have the standard QC system with ISO 140001 ,And we are
vendor for VARTA, We have to pass the quality inspection every
year, we control all the product process from the raw material to
the finished battery pack
Similar Model
| No. | Cell No. | Pack | Norminal Voltage(V ) | Norminal Capacity(mAh) | Continuous Discharge | Burst Discharge | Thickness ±0.2 mm | Width ±0.5 mm | Length ±1.0 mm | Approx Weight (g) |
| 1 | 683480SP-1500 | 3S1P | 11.1V | 1500 | 25 | 50 | 22.5 | 36 | 87 | 140 |
| 2 | 803496XP-2200 | 3S1P | 11.1V | 2200 | 35 | 70 | 26 | 35 | 105 | 195 |
| 3 | 8043125SP-4000 | 3S1P | 11.1V | 4000 | 25 | 50 | 26 | 45 | 132 | 315 |
| 4 | 883496SP-2600 | 3S1P | 11.1V | 2600 | 25 | 50 | 28.5 | 36 | 103 | 213 |
| 5 | 9543125SP-5000 | 3S1P | 11.1V | 5000 | 25 | 50 | 30.5 | 45 | 132 | 362 |
| 6 | 1043125SP-5000 | 3S1P | 11.1V | 5000 | 25 | 50 | 32 | 45 | 132 | 383 |
| 7 | 5543128SP-3200 | 3S1P | 11.1V | 3200 | 25 | 50 | 18.5 | 45 | 135 | 258 |
| 8 | 5043125SP-2500 | 3S1P | 11.1V | 2500 | 25 | 50 | 17 | 45 | 122 | 198 |
Application for Lipo Battery For Unmanned Aerial Vehicle battery
pack 11.1v 35C 5000mah
Similar production Photos
The other application for polymer lithium battery pack
