Unmanned Aerial Vehicle Battery Pack 11.1v 35C 6000mah Polymer ion
Quick Data
Nominal Capacity : 5000 mAh
Minimum. Capacity : 4900 mAh
Nominal Voltage 11.1 V
Charge Voltage: 12.6 ± 0.06V
Charge Current Standard charge: 0.5 C ( 2500 mA)
Charging Time Standard charge: 3.0 hours (Ref.) Rapid charge : 2.0
hours
Max. charge current 1.0 C ( 5A)
Cont.. Discharge Current 25.0 C ( 125A)
Max. Discharge Current 50.0( 250A)
Cutoff Voltage 9V
Resistance ≤ 10mΩ 1kHz AC Metho
Weight (Approx.) 400g
Standard Discharge Capacity
The standard discharge capacity is the initial discharge capacity
of the cell, which is measured with discharge current of 2500MA
with 9V cut-off at 25±5℃, within 1 hour after the standard charge.,
Standard Discharge Capacity
Cycle Life
Each cycle is an interval between the charge at CC-CV
500TIMES
Initial internal impedance measured at AC 1kHz after 50% charge.
Status of the cell as of ex-factory
The cell should be shipped in 50% charged state. In this case, OCV
is not less than 11.4V
Packing
According to the lithium battery standard packing method. Put
electrostatic bag packing after battery in a little box,then use
carton packaging.
Storage Characteristics
Capacity after storage for 28 days at 25℃ from the standard charge,
measured with discharge current
Capacity retention (after the storage) over 5000mah (85% of the
capacity at 25℃)
Warranty:
Tac battery will be responsible for replacing the cell against
defects or poor workmanship
for 12 months from the date of shipping. Any other problem caused
by malfunction of the equipment or mix-use of the cell is not under
this warranty.
Similar Model
| No. | Cell No. | Pack | Norminal Voltage(V ) | Norminal Capacity(mAh) | Continuous Discharge | Burst Discharge | Thickness ±0.2 mm | Width ±0.5 mm | Length ±1.0 mm | Approx Weight (g) |
| 1 | 683480SP-1500 | 3S1P | 11.1V | 1500 | 25 | 50 | 22.5 | 36 | 87 | 140 |
| 2 | 803496XP-2200 | 3S1P | 11.1V | 2200 | 35 | 70 | 26 | 35 | 105 | 195 |
| 3 | 8043125SP-4000 | 3S1P | 11.1V | 4000 | 25 | 50 | 26 | 45 | 132 | 315 |
| 4 | 883496SP-2600 | 3S1P | 11.1V | 2600 | 25 | 50 | 28.5 | 36 | 103 | 213 |
| 5 | 9543125SP-5000 | 3S1P | 11.1V | 5000 | 25 | 50 | 30.5 | 45 | 132 | 362 |
| 6 | 1043125SP-5000 | 3S1P | 11.1V | 5000 | 25 | 50 | 32 | 45 | 132 | 383 |
| 7 | 5543128SP-3200 | 3S1P | 11.1V | 3200 | 25 | 50 | 18.5 | 45 | 135 | 258 |
| 8 | 5043125SP-2500 | 3S1P | 11.1V | 2500 | 25 | 50 | 17 | 45 | 122 | 198 |
