    26650 24V 12AH LiFePO4 Battery Pack for Tracker Motor and Boat

    Ask Lasest Price
    Brand Name : TAC OEM ODM
    Model Number : IFR 26650 24V 12AH
    Certification : MSDS REACH ROHS
    Price : usd22-25
    Payment Terms : TT/ paypal / lc
    Supply Ability : 50000 each week
    Delivery Time : 7-25 days after order confirm
    • Product Details
    • Company Profile

    26650 24V 12AH LiFePO4 Battery Pack for Tracker Motor and Boat

    26650 24V 12AH LiFePO4 Battery Pack for Tracker Motor and Boat

    Specification for 26650 24V 12AH LiFePO4 Battery Pack for Tracker Motor and Boat

    No.

    Item

    General Parameter

    Remark

    1

    Combination method

    8S 1P

    2

    Combination standard

    Capacity difference≤1%

    current-maintaining ability:
    storage 28 days in 20+2℃ after full charged.

    Resistance difference ≤3 mΩ
    current-maintaining ability
    3

    Rated Capacity

    Typical

    3.3Ah

    0.2C5A discharge after Standard charge(package)

    Minimum

    3.2Ah
    4

    Nominal Voltage

    25.6V

    Mean Operation Voltage

    5

    Voltage at end of
    Discharge

    16V

    Discharge Cut-off Voltage

    6

    Charging Voltage

    29.2V
    7

    Internal Impedance

    ≤150mΩ

    Internal resistance measured at AC 1KHZ after 50% charge

    The measure must uses the new batteries that within one week after shipment and cycles less than 5 times

    8

    Standard charge

    Constant Current 0.2C5A
    Constant Voltage29.2V
    0.05C5A cut-off

    Charge time : Approx 6 h

    9

    Standard discharge

    Constant current 0.5C5A
    end voltage 16V

    10

    Maximum Continuous Charge Current

    1C5A

    Charge and Discharge Performance And Whole Pack Dimensions


    No.

    Item

    General Parameter

    Remark

    11

    Maximum Continuous Discharge Current

    1.5C5A
    12

    Operation Temperature Range

    Charge: 0~45℃

    60±25%R.H.
    Bare Cell

    Discharge: -10~60℃
    13

    Storage Temperature Range

    Less than 1 year: -20~25℃
    (-20~25℃)

    60±25%R.H.
    at the shipment state

    less than 3 months: -20~40℃
    (-20~40℃)

    Less than 7 day : -20~65℃
    (-20~65℃)

    14

    Dimensions

    71*93*230

    MAX
    (Unit: mm)

    15

    Weight

    2250gApprox
    16

    Volumetric specific energy

    151WH/LApprox
    17

    Gravimetric specific energy

    102.4WH/KGApprox




    Main Applications :

    1. Utility meter (water, electricity, gas meter,AMR)

    2. Alarm or security equipment (smoke alarm system, detector)

    3. GPS tracking

    4. Teal time clock

    5. Digital control machine

    6. Military

    7. Remote monitoring systems

    8. Car electronics

    9. Camera

    Cautions in use


    To ensure proper use of the battery please read the manual carefully before using it.
    . Handling

    • Do not expose to, dispose of the battery in fire.
    • Do not put the battery in a charger or equipment with wrong terminals connected.
    • Avoid shorting the battery
    • Avoid excessive physical shock or vibration.
    • Do not disassemble or deform the battery.
    • Do not immerse in water.
    • Do not use the battery mixed with other different make, type, or model batteries.
    • Keep out of the reach of children.

    . Storage

    • Store the battery in a cool, dry and well-ventilated area.

    . Disposal

    • Regulations vary for different countries.
    • Dispose of in accordance with local regulations.


    Period of Warranty

    Because batteries utilize a chemical reaction, battery performance will deteriorate over time even if stored for a long period of time without being used. In addition, if the various usage conditions such as discharge, ambient temperature, are not maintained within the specified ranges the life expectancy of the battery may be shortened or the device in which the battery is used may be damaged by electrolyte leakage. Please change the battery in time.

    Packing and Delivery

    the photos similar as below

    Other Similar Pack Photo
































































    Quality 26650 24V 12AH LiFePO4 Battery Pack for Tracker Motor and Boat for sale
