Brand Name : | TAC |
Model Number : | 9V 230mAh |
Certification : | MSDS REACH |
Price : | usd 2.0+ usd1.6 |
Payment Terms : | T/T, LC, Paypal etc. |
Supply Ability : | 500000pcs per week |
Delivery Time : | 10-25 days |
Specification For Ni-MH Batteries 9V 230mAh Batteries With Charger For Microphone
Test | Unit | Specification | Conditions | Remarks | |
Capacity | mAh | Typical | 230 | Standard Charge/Discharge | Up to 3 cycles are allowed |
Minimum | 220 | ||||
Open Circuit Voltage (OCV) | V | ≥1.25 | Within 1hr after standard Charge | Up to 3 cycles are allowed | |
Internal Impedance(Ri) | mΩ | ≤80 | Upon fully charge (1kHz) | Unit cell | |
High Rate Discharge (1C) | min | ≥48 | Standard Charge before discharg | End Voltage is 1.0V | |
Overcharge | N/A | No leakage nor explosion | 80mA(0.1C) charge 1 year no leakage nor explosion | ||
Charge Retention | mAh | ≥65% | Standard Charge, Storage: 28 days, Standard Discharge | ||
IEC Cycles Test | Cycle | >500 | IEC 61951-2(2003) | (see Note 3) |
![]() |
