Usb Emergency Car Jump Starter 19v Petrol With ABS + PC / Double
USV
Quick Detail:
| Place of Origin: | China | Brand Name: | TAC | Model Number: | EC0004 |
| Dimension: | 170*80*28mm | Weight: | 470g | Capacity: | 16800mah |
| Input: | 12V/ 1A | Air Pump: | 2.5Kilos | Socket Type: | USB |
| Car Output | 12V | Star Current | 200A | Peak Current | 400A |
| Output1: | 5V /12V 2A； | Output2: | 16V/19V 3.5A | | |
| Material: | ABS+PC | Warranty: | One Year | Life span: | 3-5years |
| Features: | 1. Start Cars: 12V vehicle around 20 times. ( Gasoline vehicle,
displacement <3.0L; Diesel vehicle, displacement< 2.8L) 2. Air charging for 6 minutes (2.5Kilos, 100Pa) 3. Multifunction LED light:torch/SOS/strobe, with three colors:
white/red/blue 4. Double USV output 5. With safety hammer and Emergency blade 6. Certification: CE, FC,ROHS 7. MOQ: 100set 8. Pretty appearance, 3*1W gorgeous colorful LED lights. |
Packaging & Delivery:
| Packaging Detail: | Tool box for each set, 10sets/CTN Tool Box: 32*26*8cm Carton Size: 57*34*42cm |
| Delivery Detail: | Samples 1-3days; Quantity Order 7-15days |
Specifications:
| Products | Mini Jump Starter portable for carry with flashlights |
| Model NO | EC0006 Yellow Case |
| Capacity | 16800mAh |
| Input | 12V 1A |
| Output | 5V/2A; 12V for car |
| Battery type | Polymer Lithium Ion for High Power Type |
| Dimension | 170*80*28mm |
| Charge Time | 5-7 Hours |
| Working temperature | -20-60°C |
| Weight | 470g |
| Lifespan | About 3-5 years |
| Warranty | One Year |
Mini Jump Starter Operation Guidance
Indicator Lights
Press the switch button to check the capacity of Jump Starter.
| Indicator Light | 1 Flashing | 1 solid | 2 solid | 3 solid | 4 solid |
| Battery Capacity | 0% | 25% | 50% | 75% | 100% |
When charging, indicator lights will flash one by one. The number
of solid indicator lights indicates the
battery capacity of Jump Starter. Full indicator lights are solid
when charging is puase or complete.
Jump Starter Accessories:
How to Charging for Jump Starter Itself:
1. Plug the home adaptor into the universal socket.
2. Connect 12V 1A input port of Jump Starter to the other end of
home adaptor.
3. Or
4. Plug the car adapator into the socket of cigaretter lighter.
5. Connect 12V 1A input port of Jump Starter to the other end of
car adaptor
How to Use the Mini Jump Starter for car:
1. Make sure that the number of indicator light is not less than 3.
2. Connect the red battery clamp of jumper cable to vehicle’s
positive (+) battery terminal and connect
the black battery clamp of jumper cable to the vehicle’s negative
(-) battery terminal.
3. Plug the cord of jumper cable into the jump start socket.
4. Start the vehicle
5. WEhen the vehicle starts, remove jumper cable from Jump Starter
and disconnect red and black
clamps to the vehicle battery terminal within 30 seconds.
6. Leave the vehicle’s engine running.
How to Charging mobile phones or tablets:
1. Plug the switch cable B to USB 5V 2A output port
2. Select appropriate connector for your mobile phone or tablet and
connect it the switch cable
B and your mobile phone or tablet.
3. Press the switch button to charge.
How to charge 12V vehicle products or 12V electronics:
1. Plug the optional switch cable to 12V 2A output port.
2. Connect the optional switch cable and 12V vehicle product or 12V
electronics
3. Press the switch button to power supply.
LED Illumination:
Press the switch button 3 seconds to start the LED illumination and
then 4 modes of LED light appear
in sequence ( normal, strobe, SOS, off) if you press lightly.
Mini Jump Starter Tool Box:
Features:
• High-capacity lithium ion battery provides longer life and more
charge cycles
• Once full charged, the jump starter can start the car more than
20 times.
• LED indicator shows charging and battery status
• Protection board inside, with the function like over charge, over
discharge,
over-current, overload, under-voltage and short-circuit etc.
• Outdoor lighting & flah signal
• Fast charge, the charge time is about 4-5hours.
• Small size & light weight
• Broad application for all USB devices, including smartphones, mp3
players, tablets and digital products.
• 12 months warranty
• Suppy OEM & ODM and custom service
Advantages:
• Inside Li-polymer battery which is environment and much safer and
more stable, and UL listed.
• Each jump starter with Anti-explosion test, anti-reverse
protection, short-
circuit protection, overload protection, over-temperature
protection.
• Excellent production line for high quality products and punctual
delivery time.
• We are 100% responsible for our products,we consider Customer
first,quality first and Reputation first.
Contents:
- Jump Starter
- Jump Starter cable with clamps
- Car Charger
- Home Charger
Option Contents:
- Switch cable for mobile phone
- Switch cable for laptop
- Owner’s manual
- Air Pump
- Tool box
- Color Box
Q&A:
1. What is the car jump starter?
Car jump starter is used to charge your car battery and start the
engine. Also, this is multi funcation,
except starting your vehicle, also apply to use to most of the
digital products, such as mobile phones,
laptops, cameras, etc.
2. How to turn off the product?
The product will turn off automatically after 10 seconds when no
loading is detected or the charge
has completed.
3. How long does full charge of the jump starter?
It takes 4 to 5 hours to full charge car jump starter with 12V/1A
charger.
4. How many times can this appliance on full charge start the
vehicle?
Each jump starter with different capacity, approximately 20 to 40
times.
5. How long will the power of the battery remains?
3-6 months, however, we suggest you charge it every 3 months. And
the LED illumination is another
extra function used commonly, long press the switch button to start
the flashlight, 3 modes for
options: hard light; frequent flash; SOS. The mode will be changed
after one more press.
6. months, however, we suggest you charge it every 3 months. And
the LED illumination is another
extra function used commonly, long press the switch button to start
the flashlight, 3 modes for
options: hard light; frequent flash; SOS. The mode will be changed
