12V Deep Circle Battery Pack 20AH with Wide Temperature For Electric Fish Machine

Product Categories

Guang Zhou Sunland New Energy Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Add to Cart

Feature for 12V Deep Circle Battery Pack 20AH with Wide Temperature For Electric Fish Machine

1) The cycle life is about 2000 times ,long circle life

2) Environment friendly the cell passed Rohs

3) High energy for 100% truth capacity

4) Application widely,such as solar product,electronic machine and so on.

5)The battery with black plastic case

No.	Item	General Parameter	Remark
1	Rated Capacity	20.0Ah	Standard discharge(0.2 C5)after standard charge(0.2 C5)
2	Minimal Rated Capacity	19.5Ah	Standard discharge(0.2 C5)after standard charge(0.2 C5)
3	Nominal Voltage	12.8V
4	Cycle Life	Higher than 60% of the Initial Capacity of the Cells	◆Charge: CC@0.2C to 14.6V, then CV till current to 0.05C ◆Rest: 30min. ◆Discharge: 0.2C to 10.0V ◆Temperature:20±5℃ ◆Carry out 2000cycles
5	Discharge cut-off voltage	9.2V
6	Charging cut-off voltage	14.8V
7	Cell and assembly method	IFR26650-3.3AH	4S6P
8	Housing material	PVC

No.	Item	General Parameter	Remark
9	Standard charge	0.2C constant current(CC) charge to 14.6V,then constant voltage (CV)14.6V charge till charge current decline to ≤0.05C	Charge time : Approx 7h
10	Standard discharge	Constant current 0.2C Cut-off voltage 10.0V
11	Maximum Charge Current	7A
12	Continuous Discharge Current	7A
13	Operation Temperature Range	Charge: 0~45℃	60±25%R.H.
13	Operation Temperature Range	Discharge: -10~60℃	60±25%R.H.
14	Storage Temperature Range	Less than 1 year : 0~25℃	60±25%R.H. at the shipment state
14	Storage Temperature Range	Less than 3 months:-5~35℃	60±25%R.H. at the shipment state
15	Weight	Approx/: 2.20Kg
16	Max. Dimension	thickness/:30mm
		Width/ 159mm
		Length/ 272mm

one set pack with thick bubble pack

1 set for 1 inner box and 10 box in one carton

7-10 Days for normal standard production after the buyer confirm the pI

25-35 Days for OEM order
