72V 20AH LifePO4 Battery Pack For Motorcycle / Replacement Lead Acid Battery Pack

Product Categories

Guang Zhou Sunland New Energy Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Add to Cart

intelligent BMS for safety and reliability
self-developed BMS with temperature protection and accurate power metering function
100% aging before leaving the factory
Automatic laser spot welding to ensure the reliability
Zeiss integrated tester 100% detection battery function

Item	General Parameter		Remark
Combination method	22S4P
Rated Capacity )	Typical	20Ah	Standard dischargeafter Standard charge(package)
	Minimum	20Ah
Nominal Voltage	72V		Mean Operation Voltage
Discharge Cut-off Voltage	55V		Discharge Cut-off Voltage
Charging Voltage	80.3V
Internal Impedance	≤80mΩ		Internal resistance measured at AC 1KHZ after 50% charge The measure must uses the new batteries that within one week after shipment and cycles less than 5 times
Standard charge	Constant Current 0.2C Constant Voltage57.6V 0.02CA cut-off		Charge time : Approx6 h
Standard discharge	Constant current:0.2C end voltage 44.8V
Maximum Continuous Charge Current	20A
Maximum Continuous Discharge Current	20A
Operation Temperature Range	Charge: 0~45℃		60±25%R.H. Bare Cell
	Discharge: -20~60℃
Storage Temperature Range	Less than 12 months : -20~25℃		60±25%R.H. at the shipment state
	less than 3 months: -20~40℃
	Less than 7 day : -20~60℃
Dimensions	ODM / OEM		APPROX
Weight	14KG		APPROX
(Delivery SOC)	50%-60%
(Package)	(Paper carton + Wooden Pallet)
