    12V Lifepo4 Battery Pack 32650 Solar Street Light With Temperature Control Performance

    Ask Lasest Price
    Brand Name : TAC OEM ODM
    Model Number : IFR32650 12.8V 5AH
    Certification : MSDS REACH ROHS
    Price : USD5-10
    Payment Terms : L/C, T/T
    Supply Ability : 50000 pack for one week
    Delivery Time : 7 days for single cell 15-20 days for battery pack
    • Product Details
    • Company Profile

    12V Lifepo4 Battery Pack 32650 Solar Street Light With Temperature Control Performance

    12V Lifepo4 Battery Pack 32650 Solar Street Light With Temperature Control Performance


    Specification for 12V Lifepo4 Battery Pack 32650 Solar Street Light With Temperature Control Performance

    Remark : Maybe you call IFR32700 12V Battery Pack, Actually IFR32650 and IFR32700 is same model , The size is D=32MM H=70+/-5MM , So some buyer call 32650, and some buyer call 32700

    ELECTRICAL SPECIFICATIONS
    Nominal Voltage12.8 V
    Nominal Capacity5 Ah
    Mini Capacity5 Ah
    Energy64Wh
    Resistance≤60 mΩ
    Efficiency99%
    Self Discharge<3% per Month
    weight0.65kg
    size

    140mm

    34mm

    68mm

    DISCHARGE SPECIFICATIONS
    Maximum Continuous Discharge Current20 A
    Peak Discharge Current40 A (7.5 s ±2.5 s)
    BMS Discharge Current Cut-Off70 A ±10 A (20 ±5 ms)
    Recommended Low Voltage Disconnect11 V
    BMS Discharge Voltage Cut-Off8 V (2.0 ±0.08 vpc) (140 ±60 ms)
    Reconnect Voltage10 V (2.5 ±0.10 vpc)
    Short Circuit Protection200-500 µs
    TEMPERATURE SPECIFICATIONS
    Discharge Temperature-4 to 140 ºF (-20 to 60 ºC)
    Charge Temperature32 to 113 ºF (0 to 45 ºC)
    Storage Temperature23 to 95 ºF (-5 to 35 ºC)
    BMS High Temperature Cut-Off158 ºF (70 ºC)
    Reconnect Temperature122 ºF (50 ºC)

    CHARGE SPECIFICATIONS
    Recommended Charge Current10 A
    Maximum Charge Current20 A
    Recommended Charge Voltage14.2 V - 14.6 V
    BMS Charge Voltage Cut-Off15.2 V (3.8 ±0.025 vpc)
    (1.1 ±0.4 s)
    Reconnect Voltage14.4 V (3.6 ±0.050 vpc)
    Balancing Voltage14.4 V (3.6 ±0.025 vpc)

    Drawing


    Packing Detail


    Production Photo


    HK Tac Advantage :

    Long Service Life
    32650 Lifepo4 batteries can provide more than 2000 charge/discharge cycles, or 3-5 years standby power base on normal application

    More size for customer
    we have over 500 different size for the lithium battery, including of Lifepo4 and polymer lithium battery , we can submit all normal and specially size with your equipment


    Power system design
    Our strong R&D team submit the power system design with customer's equipment

    High Reliability
    we are manufactured with the best abailable material using state of the art technology, allowing them to perform with outstanding reliability.
