    IFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 Times

    Ask Lasest Price
    Brand Name : Sunland
    Model Number : IFR26650PE-3.4Ah 3.2V
    Certification : CE,SGS recognized,ISO9001 approved
    Price : USD 0.8-1.5/PCS
    Supply Ability : 100000 PCS PER MONTH
    • Product Details
    • Company Profile

    IFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 Times

    IFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell

    IFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 TimesIFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 TimesIFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 TimesIFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 TimesIFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 TimesIFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 TimesIFR26650PE-3.4Ah 3.2V LiFePO4 Battery Cell For Solar Light Flashlight Circle Life 2000 Times

    Specification

    1.1. Electrical characteristics

    No.ItemsTest Method and ConditionCriteria
    1Standard ChargeCharging the cell initially with constant current at 1C and then with constant voltage at 3.65V till charge current declines to 0.05C.N.A.
    2Rated Cap 0.2CCapacity measured with discharge current of 0.2C with 2.0V cut-off voltage after the standard charge.³3300mAh
    Rated Cap 0.5CCapacity measured with discharge current of 0.5C with 2.0V cut-off voltage after the standard charge.³3250mAh
    Rated Cap 1CCapacity measured with discharge current of 1C with 2.0V cut-off voltage after the standard charge.³3200mAh
    Rated Cap 2CCapacity measured with discharge current of 2C with 2.0V cut-off voltage after the standard charge.³3200mAh
    Rated Cap 3CCapacity measured with discharge current of 3C with 2.0V cut-off voltage after the standard charge.³3200mAh
    3Cycle Life

    Test condition:

    Temperature: 23± 5°C

    Charge: 1C CC to 3.65V, and CV to 0.05C cut off

    Discharge: 1C discharge to 2.0V

    80% or more of 1st cycle capacity at 1C discharge of operation

    ³ 2000 times
    4

    Storage

    Performance

    Battery cell stored at 25°C with 50% SOC
    1Month3Month6Month
    Cap Retention90%85%80%
    Cap Recovery95%90%85%
    5Initial ImpedanceInternal resistance measured at AC 1KHz after 50% charge£ 20mohm
    6Cell VoltageAs of shipment3.3V ~ 3.4V
    No.ItemsSpecifications
    1Charge cut-off voltage3.65V
    2Nominal voltage3.2V
    3Minimal capacity3300mAh @ 0.2C Discharge
    4Nominal capacity3400mAh @ 0.2C Discharge
    5Standard Charge current0.2C
    6Standard charging method1C CC (constant current) charge to 3.65V, then CV (constant voltage 3.65V) charge till charge current decline to £ 0.05C
    7Charging timeStandard charge: 2.0 hours Ref
    8Max. charge current1C
    9Max. continue discharge current1C (Cell skin temperature cannot exceed 80°C)
    10Discharge cut-off voltage2.0V
    11Operating temperature

    Charging: -10°C ~ 45°C

    Discharging: -20°C ~ 60°C

    (Cell skin temperature cannot exceed 80°C)

    12Storage temperature/humidity

    Temperature -10°C ~ +35°C

    Humidity 65%±20%RH

    (Recommended to store 23 ± 5°C for long term storage)

    13Cell Weight80.0g±1.0g
    14Cell Dimension

    Length: 65.0±0.3 mm

    Width: 26.2±0.2 mm
